Aircraft program
The fuselage of this metal aircraft has a duralumin cover and duralumin reinforcements. The cabin is fitted with organic glass in a composite frame and the pilot seats are made of composite sandwich. The wing is metal, finished with composite end arches.
The horizontal tail is formed by a stabiliser and a rudder. The stabiliser is a two-beam metal shell with composite end bends. The rudder construction is all metal.
The vertical tail consists of a keel of two-beam construction and metal rudder composed of beam, ribs and cover. The end of the keel and rudder is composed of composite arches.
The aircraft has a double hand control mechanical drawbar for elevator and ailerons. The foot control of the rudder is also dual and is rope. Steel cables are suspended between the inner pedals and the eyes of the rudder control pattern located on the keel.
The aircraft has a solid three wheel landing gear with steerable nose wheel. The main chassis wheels are equipped with hydraulic brakes controlled by the brake lever from the cab.
The aircraft as engineered: what it is built from, the systems it flies with, and its configuration — each box a theme.
Technical reference compiled with AI research; a value appears only where two independent research passes and a web fact-check agree. Gaps are deliberate.
Supplier geography and market analysis for this program — with an Analytics subscription.
Subscribe| Variant | Launch / first flight | Production end | Notes |
|---|---|---|---|
| Belmont DW 210 RG | / 2020 | Upgraded retractable landing gear variant. | |
| Belmont DW 200 | 2018 / 2018 | Two-seater lightplane, also known as Patino Classic. |
| Belmont Aero SIA |
